Wilwood DynaPro dual piston caliper
The Wilwood DynaPro dual piston calipers are fully CNC machined from premium grade alloy billet.
The FEA generated body design incorporates a fortified transition between the piston housings and the bridges. Strengthening this critical area has substantially increased its resistance to deflection and body separation under load. Reductions in overall deflection, and the subsequent decreases in fluid volume displacement, translate to increased clamping efficiency with less pedal travel.
The DPS is loaded with exclusive Wilwood performance enhancements. The calipers feature Quick-E-Clip pad retainers that support a 6812 type brake pad from the top. In addition to fast pad service without caliper removal, this feature provides substantially stronger retention over the single Quick-Clip pin and 7012 type pads used in the previous DLS models. The DPS uses heavy wall stainless steel pistons to resist corrosion and slow the heat transfer from the pads.
The heavy wall sectional thickness improves pedal firmness and adds to the overall clamping efficiency by eliminating piston backside deflection.
Calipers are fitted with replaceable stainless steel SRS bridge plates. SRS plates eliminate bridge wear caused by pad gouging. The spring-loading action of the SRS plates eliminates pad rattle and dampens the vibration harmonics that contribute to squeal during engagement.
The package is completed with internal fluid passages and four corner bleed screws that allow mounting in any front, rear, left, or right side position.
Sold INDIVIDUALLY
Note: Will only suit S-Chassis with 9mm rear rotors in conjunction with the bracket HERE
Product Information
Product Information
Shipping & Returns
Shipping & Returns
Wilwood DynaPro dual piston caliper
Wilwood DynaPro dual piston caliper
The Wilwood DynaPro dual piston calipers are fully CNC machined from premium grade alloy billet.
The FEA generated body design incorporates a fortified transition between the piston housings and the bridges. Strengthening this critical area has substantially increased its resistance to deflection and body separation under load. Reductions in overall deflection, and the subsequent decreases in fluid volume displacement, translate to increased clamping efficiency with less pedal travel.
The DPS is loaded with exclusive Wilwood performance enhancements. The calipers feature Quick-E-Clip pad retainers that support a 6812 type brake pad from the top. In addition to fast pad service without caliper removal, this feature provides substantially stronger retention over the single Quick-Clip pin and 7012 type pads used in the previous DLS models. The DPS uses heavy wall stainless steel pistons to resist corrosion and slow the heat transfer from the pads.
The heavy wall sectional thickness improves pedal firmness and adds to the overall clamping efficiency by eliminating piston backside deflection.
Calipers are fitted with replaceable stainless steel SRS bridge plates. SRS plates eliminate bridge wear caused by pad gouging. The spring-loading action of the SRS plates eliminates pad rattle and dampens the vibration harmonics that contribute to squeal during engagement.
The package is completed with internal fluid passages and four corner bleed screws that allow mounting in any front, rear, left, or right side position.
Sold INDIVIDUALLY
Note: Will only suit S-Chassis with 9mm rear rotors in conjunction with the bracket HERE
